General Data
- Mass production possibility with pneumatic system
- Reliable operation with robust metal body
- High transformer power
- Coil carcass produced with a mizture of high temperature resisant Nylon 6 (%70) and glass fiber (%30)
- Elektronic current and time control
- Talistock tipes adjusted for water cooling system
- Strong bottom plate made of durable casting
Specification
| TECHNİCAL SPECIFICATIONS | 15 KW |
| ELECTRICAL INPUT | 380V / 5 KW |
| RATED POWER | 15 KW |
| FUSE CURRENT | 63 A |
| WIDTH | 600 mm |
| LENGHT | 600 mm |
| HEIGHT | 1200 mm |
| WEIGHT | 110 Kg |
| CAPACITY | 1.5 mm + 1.5 mm |
| TECHNİCAL SPECIFICATIONS | 45 KW - VERTICAL SYSTEM |
| MAINS VOLTAGE | 2~ 380 V |
| MAXIMUM PRIMARY CURRENT | 70 A |
| PROTECTION BRAKER | 2 x 80 A |
| MAXIMUM INPUT POWER PRIMAX | 45 Kva |
| WELDING THICKNESS DKP | 4,00 + 4,00 mm |
| WELDING THICKNESS GALVANISE | 2,00 + 2,00 mm |
| SLEEVE THICKNESS | 50 mm |
| WORKING DEPTH | 35 cm |
| LEVEL | 0-99 Elektronic |
| COOLING | Water channels available |
| PROTECTION CLASS | IP 21 |
| DIMENSIONS | (e / b / y) (mm) 510 x 1070 x 1450 |
| WEIGHT | 300 Kg |
